BAOFENG UV-5R Dual Band (VHF/UHF) Analog Portable Two-way Radio with FREE UV-5R 1800mAh 7.4V Li-ion BATTERY

₱ 1,190.00 -60%

By Baofeng

In TV, Audio / Video, Gaming & Wearables » Gadgets » Walkie-Talkies


Product details of BAOFENG UV-5R Dual Band (VHF/UHF) Analog Portable Two-way Radio with FREE UV-5R 1800mAh 7.4V Li-ion BATTERY

The Seller acknowledges that this product needs the necessary approvals/licenses/permits from the authorities prior to listing the product for sale. The Seller represents and warrants that it has obtained all the necessary licenses/permits/approvals required for the sale of this product.

BAOFENG UV-5R RADIO BACKGROUND

BaoFeng Introduced the UV-5R Dual Band, Dual Display radio in 2012. Since its introduction the UV-5R has seen a massive success. The UV-5R has seen 2 major changes since its launch with the second generation being signified by BFB297 Firmware (2nd Gen.) in early 2013 and the N5R firmware tweak in August of 2014.



There are several cosmetic variants of the UV-5R. These variants have no differences from the UV-5R besides their cosmetic design along with the possible removal of the 'Band Key' (no longer required in Gen. 2).



Variations include the: UV-5R v2+, UV-5RA, UV-5RE, UV-5R+ (Plus), along with several other lesser produced variants. Some of these variations may also no longer work with case specific accessories such as the original UV-5R batteries.



Late in 2013, the UV-5R also included a new variant generation with the inverted (privacy) display series; with the introduction of the BF-F8+ and its own cosmetic variants (such as the GT-3 and 997-S).



Finally, in the fall of 2014, the UV-5R saw the introduction to its successor the 3rd. Generation BF-F8HP.



FEATURES - ORIGINAL 2012 PRODUCT LAUNCH (1ST GEN.)

The BaoFeng UV-5R is a compact hand held transceiver providing 4 watts in the frequency range of 136-174 MHz and 400-480MHz (520MHz later versions). It is a compact, economical HT that includes a special VHF receive band from 65 - 108 MHz which includes the regular FM broadcast band. Dual watch and dual reception is supported. You get up to 128 memories. Other features include: selectable wide/narrow, battery save function, VOX, DCS/CTCSS encode, key lock and built in flashlight. Selectable frequency steps include: 2.5, 5, 6.25, 10, 12.5 and 25 kHz. RF power may be selected at 4 or 1 watts. This radio comes with an SMA-Female antenna, flexible antenna, BL-5 Li-ion battery (7.4V 1500 mAh (1800mAh label)), belt clip, wrist strap, AC adapter (8.4V 600ma) and drop-in charging tray. This radio requires the PC03 FTDI programming cable.



FEATURES - UPDATED LATE 2013 PRODUCT LAUNCH (2ND GEN.)

Radio Frequency IC:



Frequency-Modulated Receiver Chip:



Power Amplifier IC :



N5R Firmware (August 2014)

VERSATILE RADIO FOR AMATEUR USE

The BaoFeng UV-5R is legal for use on amateur frequencies. The UV-5R is able to Transmit on Narrowband (12.5kHz) and Wideband (25kHz).

DUAL WATCH RECEIVER

The BaoFeng UV-5R has one built-in receiver but can "watch" two channels (semi duplex). Monitor two different frequencies (even on different bands (VHF/UHF)) and the radio will monitor both frequencies giving priority to the first station to receive an incoming call.

FM BROADCAST STATION

You can listen to the FM Broadcast radio, while still monitoring your radio frequencies in the background. Any incoming call will be given priority insuring you never miss an important call while listening to the radio.

GROUP TONES SUPPORTED

The BaoFeng UV-5R supports the most common Analog Tones. It supports CTCSS, DCS, and DTMF calling methods. Set-up your calling methods to call by group tones. Tone calling (private line) is required by most repeater applications and the UV-5R supports the latest standards



The BaoFeng UV-5R can even send DTMF tones. This allows for sending ANI (Caller ID) or remote commands that require DTMF tones

ALIAS MODELS - COSMETICALLY DIFFERENT ONLY

UV-5R5

UV-5Rv2+

UV-5RA

UV-5RE

UV-5R+ (Plus)



CUSTOMIZE YOUR OPERATION WITH CHANNELS, PROGRAMMABLE BUTTONS, AND MORE!

You can program your BaoFeng UV-5R exactly how you want it. There are 128 programmable memory channels. You can add or remove channels from scanning list using the free computer software. You can give channels alphanumeric names, using a computer. The radio has 2 power levels (5 watt maximum), allowing you to choose how far you can communicate. You can set VFO limits using the CHIRP software. You can easily program from a PC to set-up the radio to operate exactly as needed.

UV-5R SPECIFICATIONS

Frequency range:

[TX] 136 - 174MHz, 400 - 520MHz

[RX] 136 - 174MHz, 400 - 520MHz, 68-108MHz (FM Broadcast)

Channel Capacity:

128 Channels

Channel Spacing

25KHz (wide band)12.5KHz (narrow band)

Sensitivity

≤0.25μV (wide band)  ≤0.35μV (narrow band)

Operation Voltage

7.4V DC ±20%

Battery:

1500mAh

Frequency step:

2.5, 5, 6.25, 10, 12.5, 20, 25, 30 and 50KHz

Antenna:

Antenna Connector: SMA-Female / Antenna Impedance: 50Ω

Accessory Connector:

Kenwood 2 Pin Standard

Stability:

±2.5ppm

Output power:

5W / 1W

Audio Power Output

700mW/10%

  • The Buyer acknowledges that this product needs the necessary approvals/permits/licenses from the authorities prior to purchase. The Buyer represents and warrants that it has obtained all the necessary licenses, permits or approvals required for the purchase of this product.
  • 25KHz/12.5KHz Switchable (Wide/Narrow Band)
  • FM Radio (65.0MHz-108.0MHz)
  • Large Inverted LCD Display
  • LED Flashlight
  • High /Low RF Power Switchable
  • VOX
  • 50 CTCSS/ 104 DCS Tones
  • Tone searching/scanning
  • Dual standby
  • PC programmable
  • Transmitter time-out timer(TOT)
  • Busy channel lock-out(BCLO)

Specifications of BAOFENG UV-5R Dual Band (VHF/UHF) Analog Portable Two-way Radio with FREE UV-5R 1800mAh 7.4V Li-ion BATTERY

  • Brand Baofeng
  • SKU 211395914_PH-270474709
  • Model BAOFENG UV-5R Dual Band (VHF/UHF) Analog Portable Two-way Radio
  • Warranty Type Local Supplier Warranty
  • Warranty Period 7 Days
